All-Road bike with no compromises
The Pelago Stavanger is defined by its remarkable versatility, serving as the ultimate multi-purpose machine without compromise. Whether you are navigating local gravel trails, embarking on ambitious backcountry bike camping trips, or handling the daily commute, the Stavanger is engineered to handle it all. It remains the most adaptable bike in the Pelago line-up, bridging the gap between a rugged adventurer and a versatile commuter.
Timeless Scandinavian Design for Every Rider
Designed with a timeless aesthetic, the Stavanger range now includes a fresh colorway and updated decals that honor Pelago’s classic design language. The frame geometry is carefully balanced for multifunctional use, complemented by an inclusive size range that comfortably accommodates riders from 145cm to 210cm. This ensures that the signature Stavanger ride quality is accessible to almost everyone, regardless of height.
High-Quality CrMo Frame Built for Customization
Technically, the Stavanger is built to modern standards with a rigid CrMo frame and thru axles for enhanced stiffness and control. The tapered headtube offers the flexibility to easily upgrade to a carbon fork, while the frame is equipped with a vast array of mounting points for water bottles, racks, and fenders. It is a future-proof platform, featuring internal routing that is both dropper post ready and Di2 compatible.
Modern Performance with GRX 1×11 drivetrain
The Stavanger offers high-performance to suit every rider’s needs. All of our campaign Grey Terra models are setup with Shimano GRX 1×11 drivetrain. With generous tire clearance and a focus on well-thought-out details, the Stavanger remains the no-compromise solution for those who demand a single bicycle that can truly do everything.
• Frame size (1) is measured from the center of the Bottom Bracket Axis to the top of the Seat Tube (C-T).
• Rider Height suggests the average sizing for the bike-rider fit. If your height is between two sizes, choose the smaller size for more comfortable riding position.
• Stand Over Height (2) tells the height of the top tube measured from the ground. Your Inseam should always be higher than the Stand Over Height. (2)
| COLOUR | Grey Terra |
| SIZES | 42 / 45 / 48 / 51 / 54 / 57 / 60 / 63 |
| FRAME | Double butted, oversize, 4130 Cr-Mo tubing, Tig-welded |
| FORK | Casted Crown 4130 Cr-Mo, 58 mm rake |
| GEARS | Shimano GRX 1X11 (2X compatible with Gravel/Road Wide chain line and max 48T chainring) |
| SHIFTERS | Shimano GRX RX600 |
| CRANKS | Shimano GRX FC-RX600, 40T 170mm |
| BOTTOM BRACKET | Shimano Hollow Tech |
| CASSETTE | Shimano Deore CS-M5100 11-42 |
| CHAIN | Shimano GRX RX600 40T |
| BRAKES | Shimano GRX RX400 |
| BRAKE LEVERS | Shimano GRX RX600 |
| SADDLE | Pelago Outback |
| REAR HUB | Novatec D792SB 12×142 |
| FRONT HUB | Novatec D791SB 12×100 |
| RIMS | WTB STi25, 32H, tubeless ready |
| TIRES | WTB Riddler 700x45C, tubeless ready (installed with inner tubes) |
| FRONT LIGHT | Not included |
| REAR LIGHT | Not included |
| HANDLEBAR | Kalloy 420-460 w/ 12° flare |
| SEATPOST | Kalloy 27,2mm (w/shim) |
| STEM | Kalloy 31.8 80mm |
| HEADSET | Acros tapered, external cups |
| FENDERS | Not included |
| PEDALS | Not included |
| KICKSTAND | Not included |
| ACCESSORIES | Carriers front and rear, frame lock, lights, grips, basket |
| TIRE CLEARENCE | 45-622 / 50-584 With fenders, 50-622 / 57-584 Without fenders |
| WEIGHT | 12,12kg (size 54) |
| WEIGHT CAPACITY | 130 kg (rider + luggage) |
|
SIZE |
SYMBOL | 42 | 45 | 48 | 51 | 54 | 57 | 60 | 63 |
|---|---|---|---|---|---|---|---|---|---|
| EFFECTIVE TOP TUBE LENGTH | A | 505 | 520 | 535 | 555 | 575 | 595 | 610 | 625 |
| SEAT TUBE LENGTH | B | 420 | 450 | 480 | 510 | 540 | 570 | 600 | 630 |
| STANDOVER HEIGHT (mm) | C | 725 | 747 | 768 | 798 | 822 | 852 | 886 | 916 |
| STEERING ANGLE | D | 70° | 71° | 72° | 72,5° | 72,5° | 72,5° | 72,5° | 72,5° |
| SEAT TUBE ANGLE | E | 75° | 74,5° | 74° | 73,5° | 73° | 73° | 73° | 73° |
| HEAD TUBE | F | 96 | 96 | 107 | 133 | 155 | 188 | 225 | 257 |
| CHAINSTAY LENGTH | G | 428 | 428 | 428 | 428 | 428 | 434 | 434 | 440 |
| BB DROP | H | 70 | 70 | 70 | 65 | 65 | 65 | 60 | 60 |
| STACK (mm) | I | 515 | 529 | 543 | 565 | 586 | 618 | 648 | 679 |
| REACH (mm) | J | 371 | 377 | 384 | 393 | 401 | 410 | 415 | 421 |
| FORK RAKE | K | 58 | 58 | 58 | 58 | 58 | 58 | 58 | 58 |
| WHEELBASE | L | 1016 | 1019 | 1021 | 1034 | 1049 | 1075 | 1092 | 1112 |
| RIDER HEIGHT | 146-152 cm | 152-158 cm | 158-164 cm | 164-172 cm | 172-180 cm | 180-186 cm | 186-194 cm | 194-210 cm |
All dimensions are preliminary and are subject to change.
Which frame size is right for me?
The ideal frame size depends on your height, your inseam, and your personal riding position preferences.
The frame size is measured from the center of the bottom bracket to the top of the seat tube (C-T). To determine the correct size, compare your height to the recommended size chart, and check that your inseam is slightly taller than the standover height of the frame (the height of the top tube from the ground). This ensures you can comfortably and safely stand over the bike.
If your height falls between two sizes, we always recommend sizing down to achieve a more agile and comfortable riding position. If you are still unsure about the sizing, feel free to contact our customer service at contact@pelagobicycles.com – we are happy to help you find the perfect fit!
Can the Pelago Stavanger be set up with a 2x drivetrain?
Yes, absolutely. Even though the standard complete bike comes with a 1x (single chainring) setup, the frame is fully compatible with a 2x (double chainring) front derailleur.
You can use wide-stance gravel or road groupsets, such as Shimano GRX or compatible 2x SRAM systems.
Note: Triple (3x) cranksets have not been tested for compatibility.
What kind of accessories can I mount on the Pelago Stavanger?
The Stavanger is an extremely versatile year-round commuter and touring bike. The frame features numerous mounting points across the fork, down tube, top tube, and seat tube.
It is fully compatible with all Pelago front and rear racks, fork racks, and can hold up to three water bottle cages. Additionally, you can easily install full-coverage fenders.
Are fenders compatible with the Stavanger, and what width should I choose?
Yes, the Stavanger accommodates mudguards. We recommend a 55 mm width, which leaves plenty of clearance for wider tires and studded winter tires.
If you plan to use mudguards simultaneously with a rear rack, the mudguard must be installed using a dedicated riser kit.
